Control System of gypsum board manufacturing machine

Automatic Electrical Control System

Remotely diagnose and remotely detect the operating conditions of system equipment by using Internet of Things and cloud service technologies;

Use a fail-safe CPU module to restore or maintain the safe state as soon as possible in the event of a failure;

The master computer control screen has a friendly interface and is easy to operate; it shows archive storage of various operational data, confirmation of alarm information, preservation of various operational actions, and dynamic display of operating status of each device, etc.;

Use professional energy management software to make the energy consumption of the production process transparent;

Safe and convenient remote service function, and it can respond in time if there is a problem;

Authorized users can monitor the production process via the Internet;

The high-reliability, easy-to-maintain, easy-to-expand fieldbus system is used, and the optical fiber ring network is used between each PLC control station;

According to the process, it is divided into 4 PLC control stations, equipped with the master computer, and set up the engineering station for maintenance, optional redundant server system;

The PLC control system can be configured according to customers’ requirements, and the conventional configuration is based on the SIMATIC S7-1500 or AB CompactLogix series.
