HEBEI LVJOE MACHINERY MANUFACTURING GROUP CO.,LTD.
Professional in designing and manufacturing all kinds of gypsum equipments
Professional in designing and manufacturing all kinds of gypsum equipments
 |
| Place of Origin: | Shi Jiazhuang, Hebei |
| Brand Name: | LVJOE |
| Certification: | ISO9001, SGS |
| Model Number: | LVJOE202203 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD390000 |
| Packaging Details: | 40 HQ for long distance shipment |
| Delivery Time: | 3 months |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 10 sets per year |
| Name: | Gypsum Board Making Machines | Raw Material: | Natural Gypsum Or FGD Gypsum |
|---|---|---|---|
| Capacity: | 2-50 Million M2 | Automation: | Automatic |
| Length Of Workshop: | 85m | Width Of Workshop: | 30m |
Product Name:
gypsum board making machinery automatic
gypsum board making machinery
automatic gypsum drywall making machinery
gypsum board production line
gypsum board making machines
Consumption of Raw Material for the Gypsum Board Production Line
(Take 9.5MM thickness board for example)
| Raw Material Designation | Consumption(KG/M2) |
| Gypsum Powder | 5.7-6.1 |
| Faced Paper | 0.42 |
| Water | 4.3-4.9 |
| Modified Starch | 0.25-0.3 |
| Foaming Agency(Vesicant) | 0.008-0.011 |
| Emulsion(White latex) | 0.006-0.007 |
| Electricity | 0.3-0.4 kWH |
| Coal | 0.7-1.0Kg(6000 Kcal) |
Requests of gypsum powder
| S.N | Items | Unit | Index |
| 1 | Initial setting time | mim | ≥6 |
| 2 | Final setting time | mim | ≤13 |
| 3 | 2h breaking strength | MPa | ≥2.0 |
| 4 | Contents of CaSO4·2H2O | % | ≤5% |
| 5 | Contents of CaSO4·1/2H2O | % | ≥75% |
| 6 | Contents of CaSO4 | % | ≤5% |
Main Process:
1. Dosing system
Accurate dosing for each raw material. Starch mixing tank use stainless steel, with long service life and low corrosive.The foaming agent reserve tank is made of stainless steel. Foaming system adopts domestic advanced technology-Dynamic and static foaming system, ensuring the finished board is lightweight, good toughness and saving much cost.
2. Paper supply system
Application:used to provide paper to the gypsum board.
Composition::The paper roll lifting machine, uncoiling device, pneumatic paper receiving machine, paper storing machine, paper pulling machine, paper guiding machine, scoring machine and automatic correction machine.
3. Forming&Solidification system
Application: to form the semi-finished gypsum board products from the gypsum powder slurry
4. Automatic cutting system
The cutting machine uses dual-serve motor, only1 mm gap between cutting saw, saving cost .
5. Distribution system
Application: used to transport the wet gypsum board to each story of drying machine with the control of PLC distributor.
6. Drying system
We have hot air technology and conduction oil technology, drying room temperature is uniform
7. Electronic control system
High electrical automation degree, low failure rate, less workers.
HeBei LVJOE Machinery Manufacturing Group Co.,Ltd was established in 1998, it's a diversified development enterprises with researching, designing, manufacturing, international trade, project equipment integration. We are strong company nationally of comprehensive strength in the gypsum equipment industry. LVJOE had won a lot of national awards, such as high-tech enterprise certificate, gypsum construction equipment research center certificate, many patent certificates about gypsum equipment issued by relative government departments. The European Union issued issued CE quality system certification, ISO9001 quality system certification. We set up the gypsum construction research center in 2011, is praised as a municipal civilization unit in HeBei Province, the contract and promise keeping unit.
